Plastic shreddering WLK 800

Weima

WEIMA WLK 800 is designed for high throughput rates and shredding most types of plastic (plastic lumps, pipes, automotive scrap, blow-molded materials PE/PET/PP bottles, buckets, and containers). As well as paper, cardboard, and light metals.

Description

  WL 600 WL 4 WLK 4 WL 6 WLK800 WL 8
Rotor diameter [mm] 260
Rotor length [mm] 600 600 600 800 800 1,000
Rotor speed [rpm] 80 – 125
Drive power [kW] 15 – 18.5 11 – 18.5 18.5 – 22 15 – 22 22 – 37 22
Max. number of knives [pcs] 14 28 28 42 42 54
Available knife sizes [mm] 40
Fraction size [mm] 10 – 40 10 – 40 15 – 40 10 – 40 15 – 40 10 – 40
Exhaust connection [mm] 160 160 – 200 – 200
Hopper opening [mm] 600 × 800 600 × 1,050 600 × 800 800 × 1,250 800 × 1,450 800 × 1,250
Length [mm] 1,805 2,045 2,045 2,045 2,590 2,045
Width [mm] 1,118 1,190 1,313 1,540 1,745 1,740
Height [mm] 1,645 1,640 1,685 1,840 2,180 1,840
Weight [approx. kg] 1,100 1,300 1,700 1,700 2,800 2,200
