Log Carrier CEK
- Log gripping by hydraulic cylinders with 2 selectable closing pressures.
- Sliding of vises on flat slides, made with interchangeable wear elements.
- Automatic positioning of the vices through programmable electronic divider.
- Log turner incorporated in the slides of each vice with hydraulic lifting with arm inclination up to 90 degrees and standard rotation via electric motor. On request, hydraulic motor.
- Centralized and automated lubrication system.
- Simultaneous movement of the vices through a single brushless motor, with high precision gears and racks and backlash recovery.
- Independent headblock displacement, each one driven by a brushless motor for rapid and accurate log centering.
- Possibility of synchronized headblock displacement.
- Optional log centering through photocells and scanner with cut optimization’s.
Description
| CEK variations |
 |
|
|---|---|---|
| Version with movable pads | A=1.000 mm | |
| Version with movable hooks | A=930 mm | |
| Speed of headblock displacement | 500 mm/s | |
| Speed of hydrostatic feed (IEC) |
10 ÷ 140 m/min | |
| Tractive force of hydrostatic feed (IEC) | 11.770 N | |
| Weight | 7.150 Kg |
(IEC) – Standard published by and according to International Electrotechnical Commission
